HTHP Stirred Fluid Loss Tester

HTHP Stirred Fluid Loss Tester/

Introduction/

HTHP Stirred Fluid Loss Tester is designed according to API Spec 10, is more suitable for measuring fluid loss property for a mixer unit in it.

 Configurations/

1. Control Assembly consists of control circuit, temperature controller, thermocouple for collecting temperature and a cooling jacket for cooling slurry cylinder。

500*650*890mm/ (64kg)

1. Slurry cup assembly consists of stainless slurry cup resisting HTHP for holding sample, and mixing slurry cylinder can mix slurry at the speed of HTHP.

Specifications

Cylinder Regulator Pressure/：0—14MPa

Filter Regulator Pressure/: 0—1.1MPa

Programmable Temperature Controller/: 0—232℃

Input Voltage/: 220V

Heater Power/: 0.7KW

Environment Temperature/: 16~32℃

Maximum Pressure of Cooling water/: 0.2-0.6MPa

Maximum Cylinder Pressure/: 13.8MPa

Slurry Volume/: 275ml

Cylinder Volume/: 500ml

Filter Press Cylinder Volume/: 100ml

Paddle Rotational Speed/: 150rpm

Marked Measuring Cylinder Volume/: 50ml
